產品概述：
施耐德NSX系列新一代塑殼斷路器Compact NSX,集全面的電能管理于極致保護。NSX繼承了NS的所有技術特長,并且超越NS，630A以下的NS已全部停產，NSX內置雙芯互感器,可以實現電力參數的精準測量。FDM121柜門顯示單元可以實現數據的海量顯示“即插即用”的便捷通信網絡架構技術,方便搭建復雜通信網絡。100A，160A，250A，400A，630A。

分斷等級：36KA，50KA，70KA，100KA，150KA。

安裝方式：固定式，插入式，抽出式。

操作方式：撥動手柄，旋轉手柄，延伸旋轉手柄，電動操作機構。

脫扣單元：TM-D, Mic2.2, Mic2.3, Mic5.2A, Mic5.3A, Mic5.2E, Mic5.3E, Mic6.2A, Mic6.3A, Mic6.2E, Mic6.3E, MA, 1.3M, Mic6.2E-M, Mic6.3E-M, Mic2.2G，等。

實現功能：配電保護、電動機保護、發電機保護、400Hz應用、負荷開關、雙電源切換系統，等。

參數測量功能：A或E型脫扣單元，可以實現多種電力參數的測量。

柜門顯示單元FDM121，可以顯示所有脫扣單元測量的信息。

Modbus通信模塊，配合BSCM（斷路器狀態控制模塊）以及帶通信功能的電操，可以實現四遙功能。

附件齊全：

SDx可以實現故障診斷功能，特別是可以實現過載指示功能。

新的電操及旋轉手柄，柜門開孔尺寸統一。

NSX接線附件，連接電子脫扣單元與FDM121柜門顯示單元或通信模塊。

口袋電源，方便客戶隨時檢查斷路器液晶顯示屏及“Ready”LED準備就緒指示燈。

精準測量

A型和E型脫扣單元內置雙重互感器專利技術，可以精確測量各種電力參數。

A型可以測量電流參數。

E型可以測量電流、電壓、功率、功率因數、頻率、電量、諧波畸變率等參數。

全面電能管理

Mic5及6脫扣單元可以實現多種電力參數測量、報警、故障診斷、運行時間、歷史日志等功能。

維護與配置模塊可以實現多種設置、模擬報警、檢查脫扣曲線等功能。

SDx可以實現故障診斷及故障的分類指示功能，特別是可以提供過載指示功能。

SDTAM可以實現電動機的過載預報警功能。

多種的軟件RSU、RCU、PowerView, 輕松實現電能管理。

產品選型：

產品實圖
參數及訂貨號對照表：

塑殼斷路器
Compact NSX100/160/250
固定式完整斷路器
Compact NSX100/160/250F
帶熱磁脫扣單元TM-D
Compact NSX100F (36 kA 380/415 V)
額定電流	3P 2D		3P 3D	4P 3D	4P 4D
TM16D	LV429627		LV429637	LV429647	LV429657
TM25D	LV429626		LV429636	LV429646	LV429656
TM32D	LV429625		LV429635	LV429645	LV429655
TM40D	LV429624		LV429634	LV429644	LV429654
TM50D	LV429623		LV429633	LV429643	LV429653
TM63D	LV429622		LV429632	LV429642	LV429652
TM80D	LV429621		LV429631	LV429641	LV429651
TM100D	LV429620		LV429630	LV429640	LV429650
Compact NSX160F (36 kA 380/415 V)
額定電流	3P 2D		3P 3D	4P 3D	4P 4D
TM80D	LV430623		LV430633	LV430643	LV430653
TM100D	LV430622		LV430632	LV430642	LV430652
TM125D	LV430621		LV430631	LV430641	LV430651
TM160D	LV430620		LV430630	LV430640	LV430650
Compact NSX250F (36 kA 380/415 V)
額定電流	3P 2D		3P 3D	4P 3D	4P 4D
TM125D	LV431623		LV431633	LV431643	LV431653
TM160D	LV431622		LV431632	LV431642	LV431652
TM200D	LV431621		LV431631	LV431641	LV431651
TM250D	LV431620		LV431630	LV431640	LV431650
帶電子脫扣單元Micrologic 2.2 (LS		0I)
Compact NSX100F (36 kA 380/415 V)
額定電流			3P 3D	4P 3D, 4D, 3D+N/2
40			LV429772	LV429782
100			LV429770	LV429780
Compact NSX160F (36 kA 380/415 V)
額定電流			3P 3D	4P 3D, 4D, 3D+N/2
100			LV430771	LV430781
160			LV430770	LV430780
Compact NSX250F (36 kA 380/415 V)
額定電流			3P 3D	4P 3D, 4D, 3D+N/2
100			LV431772	LV431782
160			LV431771	LV431781
250			LV431770	LV431780
帶電子脫扣單元Micrologic 5.2 A (LSI,		電流表)
Compact NSX100F (36 kA 380/415 V)
額定電流			3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
40			LV429882	LV429887
100			LV429880	LV429885
Compact NSX160F (36 kA 380/415 V)
額定電流			3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
100			LV430881	LV430886
160			LV430880	LV430885
Compact NSX250F (36 kA 380/415 V)
額定電流			3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
100			LV431862	LV431867
160			LV431861	LV431866
250			LV431860	LV431865
帶電子脫扣單元Micrologic 6.2 A (LSIG,
Compact NSX100F (36 kA 380/415 V)
額定電流			3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
40			LV429003X62A40	LV429008X62A40
100			LV429003X62A100	LV429008X62A100
Compact NSX160F (36 kA 380/415 V)
額定電流			3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
100			LV430403X62A100	LV430408X62A100
160			LV430403X62A160	LV430408X62A160
Compact NSX250F (36 kA 380/415 V)
額定電流			3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
100			LV431403X62A100	LV431408X62A100
160			LV431403X62A160	LV431408X62A160
250			LV431403X62A250	LV431408X62A250

Compact NSX100/160/250
固定式完整斷路器
帶電子脫扣單元Micrologic 5.2 E (LSI,
Compact NSX100F (36 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
40		LV429003X52E40	LV429008X52E40
100		LV429003X52E100	LV429008X52E100
Compact NSX160F (36 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
100		LV430403X52E100	LV430408X52E100
160		LV430403X52E160	LV430408X52E160
Compact NSX250F (36 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
100		LV431403X52E100	LV431408X52E100
160		LV431403X52E160	LV431408X52E160
250		LV431403X52E250	LV431408X52E250
帶電子脫扣單元	Micrologic 6.2 E (LSIG, 多功能電能表)
Compact NSX100F (36 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
40		LV429003X62E40	LV429008X62E40
100		LV429003X62E100	LV429008X62E100
Compact NSX160F (36 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
100		LV430403X62E100	LV430408X62E100
160		LV430403X62E160	LV430408X62E160
Compact NSX250F (36 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, 3D+OSN
100		LV431403X62E100	LV431408X62E100
160		LV431403X62E160	LV431408X62E160
250		LV431403X62E250	LV431408X62E250
Compact NSX100/160/250N
帶熱磁脫扣單元TM-D
Compact NSX100N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D	4P 4D
TM16D		LV429847	LV429857	LV429867
TM25D		LV429846	LV429856	LV429866
TM32D		LV429845	LV429855	LV429865
TM40D		LV429844	LV429854	LV429864
TM50D		LV429843	LV429853	LV429863
TM63D		LV429842	LV429852	LV429862
TM80D		LV429841	LV429851	LV429861
TM100D		LV429840	LV429850	LV429860
Compact NSX160N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D	4P 4D
TM80D		LV430843	LV430853	LV430863
TM100D		LV430842	LV430852	LV430862
TM125D		LV430841	LV430851	LV430861
TM160D		LV430840	LV430850	LV430860
Compact NSX250N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D	4P 4D
TM125D		LV431833	LV431843	LV431853
TM160D		LV431832	LV431842	LV431852
TM200D		LV431831	LV431841	LV431851
TM250D		LV431830	LV431840	LV431850
帶電子脫扣單元Micrologic 2.2 (LS		0I)
Compact NSX100N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2
40		LV429797	LV429807
100		LV429795	LV429805
Compact NSX160N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2
100		LV430776	LV430788
160		LV430775	LV430786
Compact NSX250N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2
100		LV431872	LV431877
160		LV431871	LV431876
250		LV431870	LV431875

Compact NSX100/160/250
固定式完整斷路器
帶電子脫扣單元Micrologic 5.2 A (LSI,	電流表)
Compact NSX100N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
40		LV429892	LV429897
100		LV429890	LV429895
Compact NSX160N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
100		LV430891	LV430896
160		LV430890	LV430895
Compact NSX250N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
		LV431882	LV431887
160		LV431881	LV431886
250		LV431880	LV431885
帶電子脫扣單元Micrologic 5.2 E (LSI,	多功能電能表)
Compact NSX100N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
40		LV429006X52E40	LV429011X52E40
100		LV429006X52E100	LV429011X52E100
Compact NSX160N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
100		LV430406X52E100	LV430411X52E100
160		LV430406X52E160	LV430411X52E160
Compact NSX250N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
100		LV431406X52E100	LV431411X52E100
160		LV431406X52E160	LV431411X52E160
250		LV431406X52E250	LV431411X52E250
帶電子脫扣單元Micrologic 6.2 A (LSIG,		電流表)
Compact NSX100N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
40		LV429006X62A40	LV429011X62A40
100		LV429006X62A100	LV429011X62A100
Compact NSX160N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
100		LV430406X62A100	LV430411X62A100
160		LV430406X62A160	LV430411X62A160
Compact NSX250N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
100		LV431406X62A100	LV431411X62A100
160		LV431406X62A160	LV431411X62A160
250		LV431406X62A250	LV431411X62A250
帶電子脫扣單元Micrologic 6.2 E (LSIG,		多功能電能表)
Compact NSX100N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
40		LV429006X62E40	LV429011X62E40
100		LV429006X62E100	LV429011X62E100
Compact NSX160N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
100		LV430406X62E100	LV430411X62E100
160		LV430406X62E160	LV430411X62E160
Compact NSX250N (50 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
100		LV431406X62E100	LV431411X62E100
160		LV431406X62E160	LV431411X62E160
250		LV431406X62E250	LV431411X62E250

Compact NSX100/160/250
固定式完整斷路器
Compact NSX100/160/250H
帶熱磁脫扣單元M-D
Compact NSX100H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D	4P 4D
TM16D		LV429677	LV429687	LV429697
TM25D		LV429676	LV429686	LV429696
TM32D		LV429675	LV429685	LV429695
TM40D		LV429674	LV429684	LV429694
TM50D		LV429673	LV429683	LV429693
TM63D		LV429672	LV429682	LV429692
TM80D		LV429671	LV429681	LV429691
TM100D		LV429670	LV429680	LV429690
Compact NSX160H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D	4P 4D
TM80D		LV430673	LV430683	LV430693
TM100D		LV430672	LV430682	LV430692
TM125D		LV430671	LV430681	LV430691
TM160D		LV430670	LV430680	LV430690
Compact NSX250H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D	4P 4D
TM125D		LV431673	LV431683	LV431693
TM160D		LV431672	LV431682	LV431692
TM200D		LV431671	LV431681	LV431691
TM250D		LV431670	LV431680	LV431690
帶電子脫扣單元	Micrologic 2.2 (LS	0I)
Compact NSX100H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2
40		LV429792	LV429802
100		LV429790	LV429800
Compact NSX160H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2
100		LV430791	LV430801
160		LV430790	LV430800
Compact NSX250H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2
100		LV431792	LV431802
160		LV431791	LV431801
250		LV431790	LV431800
帶電子脫扣單元Micrologic 5.2 A (LSI,
Compact NSX100H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
40		LV429794	LV429804
100		LV429793	LV429803
Compact NSX160H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
100		LV430795	LV430805
160		LV430794	LV430804
Compact NSX250H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
100		LV431797	LV431807
160		LV431796	LV431806
250		LV431795	LV431805
帶電子脫扣單元Micrologic 5.2 E (LSI,
Compact NSX100H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
40		LV429004X52E40	LV429009X52E40
100		LV429004X52E100	LV429009X52E100
Compact NSX160H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
100		LV430404X52E100	LV430409X52E100
160		LV430404X52E160	LV430409X52E160
Compact NSX250H (70 kA 380/415 V)
額定電流		3P 3D	4P 3D, 4D, 3D+N/2, OSN
100		LV431404X52E100	LV431409X52E100
160		LV431404X52E160	LV431409X52E160
250		LV431404X52E250	LV431409X52E250
